FAN7190_F085
High-Current, High & Low-Side, Gate-Drive IC
November 2012
Features
? Automotive qualified to AEC Q100
? Floating Channels for Bootstrap Operation to +600V
? 4.5A Sourcing and 4.5A Sinking Current Driving Capa-
bility
? Common-Mode dv/dt Noise Cancelling Circuit
? Built-in Under-Voltage Lockout for Both Channels
? Matched Propagation Delay for Both Channels
? 3.3V and 5V Input Logic Compatible
? Output In-phase with Input
? 8-Lead Small Outline Package (SO 8L NB)
Applications
? Advanced Fuel Injection Systems
? Automotive high voltage DC-DC converters
? Starter/Alternator
? Electric power steering
? Motor controls (fans, compressors)
? MOSFET-and IGBT high side driver applications
Ordering Information
Description
The FAN7190_F085 is a monolithic high- and low-side
gate-drive IC, which can drive high speed MOSFETs and
IGBTs that operate up to +600V. It has a buffered output
stage with all NMOS transistors designed for high pulse
current driving capability and minimum cross-conduction.
Fairchild’s high-voltage process and common-mode
noise canceling techniques provide stable operation of
the high-side driver under high dv/dt noise circumstances.
An advanced level shift circuit offers high-side gate driver
operation up to V S =-9.8V (typical) for V BS =15V.
The UVLO circuit prevents malfunction when V DD and
V BS are lower than the specified threshold voltage.
The high current and low output voltage drop features
make this device suitable for controlling direct injection
actuators and for use in many automotive DC-DC con-
verter and motor control applications.
SO 8L NB
Part Number
FAN7190M_F085
FAN7190MX_F085
Package
SO 8L NB
Operating
Temperature Range
-40 ? C ~ 125 ? C
Eco Status
RoHS
Packing Method
Tube
Tape & Reel
For Fairchild’s definition of “green” Eco Status, please visit: http://www.fairchildsemi.com/company/green/rohs_green.html .
? 2012 Fairchild Semiconductor Corporation
FAN7190_F085 Rev. 1.0.0
www.fairchildsemi.com
